Garland/US Range Garland US Range M42-6R Master Series Heavy Duty Range
|Quantity of Burners||2|
A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
- Cast iron top grates
- Piezo Spark ignition for oven
- Stainless steel front and sides
- Fully porcelainized oven interior
- 6" (152mm) chrome steel adj. legs
- 7-1/2" (191mm) stainless steel front rail
- Stainless steel drip tray under open burners
- Removable ring grates over each open top burner
- Heavy gauge aluminized steel radiation baffle shield
- 1 heavy duty cast iron even hear top on left with 1 burner rated 30,000 BTU (8.89kW) total
- 40,000 BTU (11.72kW) natural gas, 35,000 BTU (10.25kW propane gas cast iron oven burner
- Two 35,000 BTU (10.25kw), natural or 32,000 BTU (9.37kW) 2- piece Starfire burners with removable heads
- Additional oven rack
- Stainless steel main back
- Stainless steel oven interior
- Gas regulator 3/4" or 1-1/4"
- End caps and cover (NC, specify)
- 6" (152mm) stainless steel adj. legs
- Celsius dial for oven thermostat (NC)
- Corner columns for banking – specify
- Dais base (not for use with "RC" oven)
- Rear gas connection, 3/4" or 1-1/4" NPT
- Gas shut off valve; 3/4", 1" or 1-1/4" NPT
- 230 volt, 50 cycle components, RC motor (export)
- Storage base shelf of aluminized or stainless steel
- Stainless steel tubular high shelf, single or double deck
- Convection oven base, add C to model #, e.g. M42-6RC
- Set of (4) Polyurethane non-marking swivel casters w/front brakes
- Stainless steel backguard: 10" (354mm), 17" (432mm) or 33" (838mm)
- Stainless steel common front rail up to 102" (2591 mm) wide, (two or more units in a battery)
- Gas flex hose & quick disconnect (3/4", 1" or 1-1/4" NPT x 5') w/restraining device, please specify
Heavy-duty gas range with oven, Model M42-6R, combination top. One 17" (432mm) wide even hot top, 30,000 BTU (8.79kW) on left and two 35,000 BTU (10.25kW) Starfire open burners. Heavy duty cast iron top grates/ring grates 34" (864mm) wide x 38" (965mm) deep, including 7-1/2" (191mm) deep stainless steel front rail. Porcelain enamel oven interior with 40,000 BTU (11.72kW) cast iron oven burner. Stainless steel front and sides. Natural or propane gas. Also available with storage base w/ doors, suffix S, and modular top, suffix T. NOTE: Ranges supplied with casters must be installed with an approved restraining device.
NOTE! This is a general product line video and does not necessarily reflect the listed model.
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
