Market Forge Industries F-40LF Kettle

F-40LF
Market Forge Industries F-40LF Kettle
Free Freight
Call for Price: 1-800-555-0666

Specifications
BrandMarket Forge
BaseTri-Leg
Capacity40 Gallon
DesignFull Steam Jacket
MaterialStainless Steel
Specialty OptionsDirect Steam
Weight270
Additional Information

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Description

This item is now sold under Crown

Kettle, direct steam, 40 gallon capacity, full steam jacket design, tri-leg, all stainless steel exterior finish

Standard Features:
Market Forge direct connected stationary steam jacketed kettle. Kettle will be constructed of welded satin finish stainless steel, type 304. A double wall interior around the kettle will form a full steam jacket. The kettle bottom will be of elliptical design for superior heat circulation. The 20 gallon will be on a Tri-leg mounting frame of stainless steel pipe and the 30-60 gallon will be on a Quad-leg mounting frame of stainless steel pipe. Both the Tri and Quad stainless steel pipe mounting frames will conceal the steam piping. Each leg will be fit- ted with a four-hole adjustable flange foot for securing to the floor. Unit will include as standard a Steam Control Kit (STA-1), a hinged cover and a 2” draw-off valve with strainer and a safety relief valve.
Options & Accessories: (Additional Charge)
  • „ Pantry Faucet
    • ‰ Single pantry faucet with swing spout and mounting bracket
    • ‰ Double pantry faucet with swing spout and mounting bracket
  • ‰ Strainer hook
  • ‰ BFT - Ball float trap
  • ‰ Etched Gallon Markings
  • ‰ Triple bracket assembly
  • ‰ Graduated measuring stick
  • ‰ Wall models (consult factory)
  • ‰ H.P. 50 PSI (3.5 kg/cm2) rated
  • ‰ 3” (76mm) draw-off valve with strainer
  • ‰ PRV - Pressure reducing valve when required
  • ‰ Type 316 stainless steel liner (for high acid content)
  • ‰ Prison package, s/s plate over tangent draw-off valve, tamper proof screws, chrome plated steam control, lockable spring assist hinged cover, reinforcement bar
Operation:
  • Direct steam at 5–35 PSI (0.3–2.5 kg/cm2). An optional pressure reducing valve is required if incoming pressure exceeds kettle rat- ing.
Steam Flow Requirements:
  • 34 lbs. (15.5 kg) steam per hour or 1 BHP per 20 gallons (76 liters) of kettle capacity.
Shipping Weight:
  • ‰ F-20LF - 225 lbs (102 kg)
  • ‰ F-30LF - 245 lbs (111 kg)
  • ‰ F-40LF - 270 lbs (122 kg)
  • ‰ F-60LF - 295 lbs (134 kg)
  • ‰ F-80LF - 320 lbs (145 kg)

Options
50 PSI
Marking & measuring strip
Draw-offs & disc strainers
Kits
Prison option
Warranty
