Market Forge Industries FTM(2)80LE Kettle/Mixer

Market Forge Industries FTM(2)80LE Kettle/Mixer
Free Freight
Call for Price: 1-800-555-0666

BrandMarket Forge
BaseOpen Leg Frame
Capacity(2) 80 Gallon
Design2/3 Steam Jacket Design
MaterialStainless Steel
Additional Information

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Kettle/Mixer, twin unit, electric, (2) 80 gallon capacity each, electrically heated, 2/3 steam jacket design, tilt-type, open leg base with power tilt bridge, stainless steel construction

Standard Features:
  Market Forge self-generating twin electric kettle. Construction shall be welded stainless steel type 304 satin finish. A double-wall kettle interior shall form a steam jacket around the lower 2/3 of the kettle. The bottom of the kettle shall be of hemispheric design for maximum heat transfer. (316 stainless steel liner is standard on 40-gal. for high-acid content products). The tubular legs shall be constructed of stainless steel pipe fitted with four-hole adjustable flanged feet for securing to the floor.
  A sealed stainless steel tilt mechanism shall permit the kettle to tilt forward a full 90° for complete emptying. The tilt mechanism shall be self-locking for positive stop action. Kettle controls shall include a power switch, thermostat, power “on” light (pilot light), vacuum/pressure gauge, pressure relief valve, and low-water shutoff. Thermostat range to be 140°F to 285°F (60°C to 140°C), at a maximum pressure of 50 PSI (3.7 kg/cm2). Removable heating elements rated at 24 KW.
 The mixer is a variable-speed unit powered by a 5 hp electric motor driving a hydraulic pump. Two agitators shall be included: a primary stainless steel scraper/agitator, and a secondary high-speed mixer. Both agitators shall be removable for cleaning, and no tools will be required for removal.
  The console front to have the main power switch, mixer lift switch, and variable speed control. The bridge is constructed of 10-gauge stainless steel and contains two heavy-duty hydraulic motors to drive the agitators. The bridge shall be power tilt, and swing 140° out of the way for kettle tilting or cleaning.
Options & Accessories: (Additional Charge)
  • Butterfly Valves
    • 3” Manual Butterfly Valve
    • 2” Manual Butterfly Valve
  • 33 KW Elements
  • Swing Faucet on Console
  • 440, 460 or 480 VAC, 60 Hz, 3 Phase
  • 316 Stainless Steel Liner for High-Acid Content Products (Standard on 40-Gallon)
  • Electrically self-generating closed steam system equipped for operation on:
    • 208 Volt, 3 Ph, 60 Hz
    • 240 Volt, 3 Ph, 60 Hz
Shipping Weight:
  • FTM-(2)40LE - 1350 lbs (612 kg)
  • FTM-(2)60LE - 1400 lbs (635 kg)
  • FTM-(2)80LE - 1490 lbs (676 kg)

Markings & measuring strip
Voltage choices
Disk strainers
Prison option

NOTE! This is a general product line video and does not necessarily reflect the listed model.
