Champion 76 PRO-HR Pro Series

Name: Champion 76 PRO-HR Pro Series
Brand: Champion
SKU: 76 PRO-HR
Price: 58397.5 USD
Availability: InStock

SKU#: 76 PRO-HR

Product photo not available at the moment

OPTIONS
REVIEWS
Q & A
RECOMMENDED ITEMS

Free Freight?

Quick Ship

Energy Star ?

Products with Energy Star certification are designed to be more energy-efficient to maximize savings.

$58,397.50

Sign-In here for more information

$55,185.64

or enjoy small payments $1,185.94/mo.

Calculate

Product Protection

Starting at

$$$ View Champion Promos

View all Champion Conveyor Type Dishwashers

Champion 76 PRO-HR Specifications

Brand	Champion
Energy Efficiency	Energy Star
Made in	USA
Certifications	cULus
Width (in)	760
Weight	760

Champion 76 PRO-HR Certifications

cULus

UL (Underwriters Laboratories) approval for the US and Canada

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Champion 76 PRO-HR Description

Pro Series, 76”W, (54” single tank with 22” prewash) rack conveyor dishwasher, Proportional Rinse, Progressive anti-jam drive system, top mounted Prodigy series HMI user interface, Proactive maintenance software,100 gallons per hour with energy sentinel (idle pump shut-off), (255) racks per hour, single-piece wash chamber design, single-piece stainless steel upper & lower wash arms manifolds, internal removable scrap basket, dual-piece scrap screens, 20” standard vertical clearance which accommodate 18” x 26” sheet pans, full 180° opening leak proof insulated hinged access doors, automatic tank fill, door safety switches, leak-proof ball valve drains, lower front & side enclosure panels, stainless steel heavy gauge construction including base & legs, electric tank heat with heat recovery, heat recovery cabinet to come standard with single vent cowl, internal booster heater included, 2 HP prewash & wash pump, single point machine & booster connection, vent fan control, stainless steel rear manifolds, includes: (1) 20" x 20" peg rack & (1) 20" x 20" flat rack, NSF, cULus, ENERGY STAR®, Made in USA

Options for Champion 76 PRO-HR

Hood options

20" High hood vertical clearance for sheet pans (standard) 24" Vertical clearance through machine +$2,011.59

Side loader

Cantilever side loader, 24", no hood +$6,158.06 Cantilever side loader, 30", no hood +$9,532.34

Detergent & Rinse option

Detergent & Rinse-aid pumps (mounted & inter-wired) +$1,278.33

Feet option

Flanged feet +$408.81

Splash shield

Splash shield (set) +$408.81

Water Conditioner

Champion ION scale prevention system, unmounted (1-HW,1-CW For HR or VHR Models) +$2,329.55

Ventilation options

Extended stainless steel vent cowl with 7" stack & locking damper (single) +$892.24 Stainless steel vent cowl with 7" stack & locking damper (single) +$820.86

Tank heat options

Electric tank heat with heat recovery, standard Stainless steel steam coil tank heat with heat recovery +$3,117.96

Water related options

Drain water tempering kit (un-mounted) +$1,323.76 Shock Arrestor (un-mounted) +$120.05 Water pressure regulating valve (unmounted) +$301.74

Additional racks

Flat Bottom Dishrack, 20" x 20", additional +$94.09 Peg Dishrack, 20" x 20", additional +$94.09

Connectivity

Direct Link: Features remote access service & performance diagnostics by the Champion factory technical support team +$1,946.70 Direct Link Plus: Features remote access service & performance diagnostics by the Champion factory technical support team. Includes cloud storage & online user access. Temperature & performance data is stored via the cloud and is accessed through an online portal. Initial term for this upgrade is three years. +$2,920.05

Clean dish roller table options

Roller Conveyor Table, 64", stationary, unload end, includes: whisker style table limit switch +$5,220.40 Roller Conveyor Table, 84", stationary, unload end, includes: whisker style table limit switch +$6,816.69 Roller Conveyor Table, 144", stationary, unload end, includes: whisker style table limit switch +$12,098.74

Limit switch options (must choose one)

Table limit switch, whisker style, includes: 12 ft. pre-wired cord standard (unmounted) Field installation by KEC or authorized installer. +$473.70 Table limit switch, button style, includes: 12 ft. pre-wired cord standard (unmounted) Field installation by KEC or authorized installer. +$473.70

Machine voltage

208v/60/3-ph 240v/60/3-ph 480v/60/3-ph Export voltage (consult factory for price)

Direction of operation

Left-to-right operation Right-to-left operation

Back panel

Stainless steel rear enclosure panels, priced per foot of machine (consult factory for price)

Correctional package

Low to Medium Security Package: Includes stainless steel locking grid over control cabinet, tamper proof screws, hinged lid on PW basket, welded curtain hooks, lockable doors (Locks by others), mesh cover on pressure gauge (consult factory for price) High Security Package: Includes stainless steel locking grid over control cabinet, tamper proof screws, hinged lid on PW basket, welded curtain hooks, lockable doors (Locks by others), mesh cover on pressure gauge, stainless steel grid underneath, solid conduit (consult factory for price)

Extended warranty

2nd year limited parts & labor warranty +$2,142.40 End of Warranty Tune-Up: Initial, then follow up resolution visit, during normal 8-5 business hours, at the end of the normal warranty period. Thorough diagnosis of all machine components, with proactive replacement of specific parts, including wearable parts (consult factory for wear parts). Full parts & labor coverage. If customer is beyond 60 miles from Champion authorized service agent, consult factory. +$3,749.20

What is included

Note: Complimentary factory authorized performance test included, upon equipment start-up. Consult local Champion sales representative for coordination of the start-up. If customer is beyond 60 miles from Champion authorized service agent, consult factory.
Standard warranty: 1 year parts & labor warranty, standard
Oversized shipping charge: Oversized units with crated dimension of equal to or greater than 96" for shipping will require an oversize charge. Shipping to a facility without a standard receiving dock could incur additional shipping charges related to service requested. (contact factory for price)
Water Treatment Options:: Note: For water of 3-grains of hardness or more, Champion recommends adding a water treatment device.
