Garland/US Range UN17FC54 Polar Cuisine 54" 2 Drawer Freezer Base, Stainless Steel with Marine Edge Top - 115 Volts

Garland US Range Garland/US Range UN17FC54 Polar Cuisine 54" 2 Drawer Freezer Base, Stainless Steel with Marine Edge Top - 115 Volts

UN17FC54
Stock Status
Updating. Please wait...
Free Freight
$16,907.00

Contact us for details

$12,234.00

You will earn 16907 Reward Points.

Product Protection
Coverage starting at
FINANCE

Monthly Payment *

Finance Payment Calculator
$262.91
* The above amount may vary depending on the applicant's credit history.
Attention!
Order by 10/15/2023 to save before the price increases!
  • Please see specification sheet for installation clearance requirements
  • 2023 model, meets the newest EPA and DOE codes.

Garland US Range UN17FC54 Specifications

Width Range36 to 60 Inches
Top StyleMarine Edge
SeriesPolar Cuisine
ConstructionStainless Steel
BrandGarland/US Range
Refrigerant TypeHFC-404A
Exterior FinishStainless Steel
Refrigeration SystemSelf-contained
Compressor LocationSide Mounted
Number of Drawers2
Sections1
StyleDrawers
Voltage115 Volts
Width (in)54
Height (in)26.19
Depth (in)32.75
Weight360.00

Additional Information on Garland US Range UN17FC54

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Garland US Range UN17FC54 Description

Polar Cuisine Freezer Base, self-contained refrigeration, 54" W one-section, (2) 27" drawers, stainless steel exterior, 6" stainless steel legs (available only when ordered with Cuisine Series modular cook tops) 115v/60/1-ph, 8.2 amps, (U S Range)Polar Cuisine Freezer Base, self-contained refrigeration, 54" W one-section, (2) 27" drawers, stainless steel exterior, 6" stainless steel legs (available only when ordered with Cuisine Series modular cook tops) 115v/60/1-ph, 8.2 amps, (U S Range)

Standard Features:
  • 6" (152mm) adjustable legs
  • Santoprene magnetic door gasket
  • Center located, flush mounted handle
  • Stainless steel exterior front and sides
  • Compressor Tropicalized to 100° F (38°C)
  • Front face mounted scroll type thermometer
  • Vertically mounted blower coil, HFC-404A refrigerant
  • Compressor housing located on right end of unit standard
  • Removable track assembly drawers with a 10 Year warranty for parts.
  • Heavy-duty stainless steel drawer slides with stainless steel bearings.
  • 5 Year replacement parts compressor warranty; First year parts and labor
  • ABS interior door front and cabinet sides, stainless steel interior top, rear and bottom
  • Standard drawers with mullion between drawers accommodates 12"x 20" x 4" deep hotel pans
  • Hot gas condensate evaporator on refrigerator units, freezer units have electric condensate evaporator
Optional Features:
  • Casters
  • Doors and tray racks to accommodate sheet pans in lieu of drawers, N/A on 32" drawers
  • Extra deep drawers without mullion to accommodate 6” deep hotel pans (150mm deep Gn 1/1 pans)
Specifications:
US Range low height Self-Contained Refrigerated or Freezer Base to be exclusively used under US Range Heavy Duty Cuisine Series modular tops. Stainless steel exterior front and sides. ABS interior door front and cabinet sides, and stainless steel interior top, rear and bottom. Santoprene magnetic door gasket. Galvanized steel bottom and back of base. CFC free foamed in place insulation. Removable stainless steel roller drawer assembly with self-lubricating rollers. Roller assemblies carry a 10 Year parts warranty. Standard drawers accommodate 12" x 20" x 4" deep hotel pans HFC-404A refrigerant refrigeration system supplied with condensate evaporator. 6' cord and plug (North American models only come with NEMA 5-15 plug.). Vertically mounted blower coil on inside cabinet. Units equipped with scroll type thermometer, 6" (152mm) adjustable legs standard.
NOTE : All Bases must be order with Cuisine Series or combination of Cuisine Series Modular tops Only. Please specific when ordering modular tops if they are for refrigerated base mount. U.S. Range products are not approved or authorized for home or residential use but are intended for commercial applications only. U.S. Range will not provide service, warranty, maintenance or support of any kind other than in commercial applications.

Options for Garland US Range UN17FC54

Compressor location
Custom note
Mounting options
What is included
  • Standard warranty: One year limited parts and labor warranty, 5 year replacement parts compressor warranty, standard
  • Drawer warranty: 10 Year warranty for parts on track assembly drawer system, standard
  • Note: NOTE: Polar Cuisine Series refrigerated or freezer bases are specifically designed to match Cuisine Series modular top sections
