Name: Berner ARD12-1036E Architectural Series Recessed 12 Air Door
Brand: Berner
SKU: ARE12-1036E
Price: 2473.85 USD
Availability: LimitedAvailability

Berner ARD12-1036E Architectural Series Recessed 12 Air Door

MPN#: ARE12-1036E

Berner Berner ARD12-1036E Architectural Series Recessed 12 Air Door

Photo may not represent the actual product.
Always refer to the description and spec sheet (if available).

Berner ARD12-1036E Architectural Series Recessed 12 Air Door

Berner ARE12-1036E Accessories

Berner 9503MRS1F2-NC-K Magnetic Reed Door Switch 9503MRS1F2-NC-K

$10.80

Berner 9503MRS1F2NCK-BR Magnetic Reed Door Switch 9503MRS1F2NCK-BR

$10.80

Details
Options
Q & A (0)

Description

Berner ARE12-1036E Description

Architectural Recessed 12 Series, 36" wide, electric heated, (1) 1/2 hp motor, ten speed, factory mounted Intelliswitch digital controller with touch screen, hinged white aluminum bottom access panel, recommended mounting heights up to 12', 14kW, cULus, Made in USA

Options for Berner ARE12-1036E

Special freight fees

Residential Delivery (Includes Lift Gate) +$371.00

24-48 Hour Call Ahead Fee +$56.18

Lift gate delivery +$217.30

Inside delivery +$186.56

Limited access fee +$187.62

Big city delivery ($50-$500)(contact factory for price)

Construction site delivery +$186.56

Remote delivery +$84.80

Detention ( 0-30 minutes) (if the company receiving the delivery causes delays in the unloading of the freight)

Detention ( 31-45 minutes) (if the company receiving the delivery causes delays in the unloading of the freight) +$148.40

Detention ( 46+ minutes)( +$160 for every additional 15 minutes) (if the company receiving the delivery causes delays in the unloading of the freight) +$169.60

Re-delivery ($128 Min + Variable Adder Per Wt + Variable Adder Per Zip Code) +$152.64

Re-consignment ($84 min + variable adder per wt + variable adder per zip code) +$103.88

Appointment fee +$53.00

Homeland Security Border Fee +$32.86

Storage/Warehouse Fees (per day) +$89.04

Government Location or Guard Shack +$139.92

Correction of Bills Fee +$42.40

Toggle disconnects

Toggle disconnect (contact factory for part numbers and pricing)

Thermostat

Thermostat, 2-pole, remote mounted +$46.79

Electrical accessories

Intelliswitch Display Kit – Remote Mounted with 20' maximum cable +$118.24

Finishes

Custom painted hinged bottom cover finish +$118.76

SS Stainless steel hinged bottom cover finish +$148.06

White aluminum hinged bottom cover finish, standard

What is included

Warranty: Two year parts warranty (heated units)
Special freight note: If special freight fees are requested, (See below) all applicable fees will be added to the invoice; fees subject to change; contact factory for addition information.
Freight Note: NOTE:Contact Name / Phone Number and/or Email required at time of order

Voltage

208v/60/1-ph

208v/60/3-ph

240v/60/1-ph

240v/60/3-ph

380V/50/3-ph (contact factory for price)

480/60/3-ph +$285.84

600/60/3-ph +$285.84

220v/50/1-ph (Note: This is an international voltage, please choose 240/1/60 for applications within the United States.)
