Southbend 20064SB Platinum Series 64" 2 Drawer Refrigerated Chef Base with Marine Edge Top
MPN#: 20064SB
Free Freight?
Quick Ship
$16,322.00
Product Protection
Starting at
- 2025 model, meets the newest EPA and DOE codes.
Photo may not represent the actual product.
Always refer to the description and spec sheet (if available).
Southbend 20064SB Accessories
Southbend P12C-L Low Boy Cabinet
$2,888.30
Southbend P24C-L Low Boy Cabinet
$3,702.15
Southbend P36C-L Low Boy Cabinet
$5,410.55
Description
Southbend 20064SB Description
Refrigerator Base, self-contained, low height, 64", (2) 31" self-closing drawers, full width pull handles, stainless steel exterior & 6" legs, 120v/60/1-ph, 8 amps, 1/4 HP, order with Platinum Series modular cook tops, UL, NSF
Create your own custom restaurant range by pairing a Platinum Series cooktop with this Southbend 20064SB commercial refrigerator base. Complete your setup with our amazing line of commercial chef bases and commercial refrigerators & freezers.
Features
- Self-contained refrigerator base for use in commercial kitchens
- Low height for use in compact spaces
- Measures 64 inches wide by 32.5 inches deep by 26 inches high
- Includes two 31-inch, self-closing drawers equipped with full-width pull handles
- Designed to hold standard 12- by 20- by 4-inch pans (not included)
- Durable stainless steel exterior and 6-inch legs
- Made to be paired with Platinum Series modular range tops
- CFC-free refrigeration system with expansion valve
- Foamed-in-place polyurethane insulation
- 120v/60/1-ph
- 8 amps
- ¼ HP
- UL and NSF
Options
Q & A
Specifications
Southbend 20064SB Specifications
| Width Range | 61 to 76 Inches |
|---|---|
| Top Style | Marine Edge |
| Series | Platinum Series |
| Construction | Stainless Steel |
| Brand | Southbend |
| Refrigerant Type | R-404A |
| Certifications | NSF, UL |
| Refrigeration System | Self-contained |
| Capacity | 5 - 12 cu. ft. |
| Compressor Location | Side Mounted |
| Number of Drawers | 2 |
| Sections | 1 |
| Voltage | 120 Volts |
| Width (in) | 64 |
| Height (in) | 26 |
| Depth (in) | 32.5 |
| Weight | 550.00 |
Files
Additional Information on Southbend 20064SB
Certifications
Southbend 20064SB Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
UL
UL has tested representative samples of this product and determined that the product meets specific, defined requirements.
Compare Southbend 20064SB to Other Products
Rating
Price
Width (in)
Depth (in)
Height (in)
Sections
Number of Drawers
Construction
Compressor Location
Refrigerant Type
Top Style
Voltage
Certifications
Price
$16,322.00 64
32.5
26
1
2
Stainless Steel
Side Mounted
R-404A
Marine Edge
120 Volts
NSF
Price
$23,208.00 114
34
27
3
6
Stainless Steel
Side Mounted
HFC-404A
Marine Edge
115 Volts
Price
$21,018.00 60
34.13
26
1
2
Galvanized & Stainless Steel
Side Mounted
R-404A
Flat
115 Volts
cULus
Price
$16,291.00 84
32.5
26
2
4
Stainless Steel
Remote
R-404A
Marine Edge
120 Volts
NSF
Price
$16,195.95 48
34
26
1
2
Stainless & Galvanized Steel
Side Mounted
R-404A
Marine Edge
115 Volts
Price
$22,997.00 90
32.75
26.19
3
6
Stainless Steel
Side Mounted
HFC-404A
Marine Edge
115 Volts
