Traulsen G32003 76.31'' 69.1 cu. ft. Top Mounted 3 Section Glass Door Reach-In Refrigerator

Traulsen G32003 76.31'' 69.1 cu. ft. Top Mounted 3 Section Glass Door Reach-In Refrigerator

G32003
Stock Status
Updating. Please wait...
Free Freight
$11,651.85

Contact us for your price

Call 1 (800) 555-0666
Mon-Fri 9AM-8PM, Sun 12-6PM ET

Why don't we show the price for this item?

$11,651.85

Contact us for your price

Call 1 (800) 555-0666
Mon-Fri 9AM-8PM, Sun 12-6PM ET

Why don't we show the price for this item?

You will earn 11652 Reward Points.

Product Protection
Coverage starting at
FINANCE

Monthly Payment *

Finance Payment Calculator
$250.40
* The above amount may vary depending on the applicant's credit history.
  • 2023 model, meets the newest EPA and DOE codes.
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Traulsen G32003 Specifications

Amps15 Amps
Refrigerator Capacity70.1 cu. ft.
Door SizeHalf
Hinge LocationLeft/Right
ConstructionStainless Steel and Aluminum
Half DoorsYes
BrandTraulsen
Refrigerant TypeR-134A
CertificationsNSF
Number of Doors6
Refrigeration SystemSelf-contained
Capacity47 - 70 cu. ft.
Compressor LocationTop Mounted
Door TypeGlass
Sections3
Temperature Range34 - 38 Degrees F
Voltage115 Volts
Width (in)76.31
Height (in)83.44
Depth (in)35
Weight790

Traulsen G32003 Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Traulsen G32003 Description

Dealer's Choice Display Refrigerator, three-section, 70.1 cu. ft., self-contained refrigeration, (6) half-height glass doors (hinged left/left/left), (3) epoxy coated shelves per section (factory installed), microprocessor with LED display, LED interior lights, stainless steel front, anodized aluminum sides & interior, 6" high casters, R290 Hydrocarbon refrigerant, cETLus, NSF
Dealer's Choice Display Reach-In Refrigerator, three-section, 69.1 cu. ft., self-contained refrigeration with microprocessor control, stainless steel front & half height glass doors (hinged left/left/left), lights, anodized aluminum sides & interior, (3) epoxy coated shelves per section (factory installed), 6" high casters, 3/4 HP, cULus, NSF (more commercial refrigerators and freezers available)

Standard Features:
Traulsen’s G-Series "Dealer's Choice" models meet or exceed the standard specifications and performance of most other brands top tier product offerings. Reliable, energy-efficient, and durable, with large individual storage capacities, the high-quality G-Series lineup includes a wide range of one, two, and three-section reach-in refrigerator and freezer models built in our most popular footprints. They are available with either full or half height doors, and the added convenience of a variety of different door hingings to choose from. In addition, each also includes a number of user-friendly features, making them one of the best overall equipment values in Foodservice today, and the right fit for nearly any commercial application.
  • 9' Cord & Plug Attached
  • Five-Year Compressor Warranty
  • Durable Anodized Aluminum Interior
  • Guaranteed For Life Cam-Lift Hinges
  • Three-Year Parts And Labor Warranty
  • Stainless Steel Vertical Door Handle(s)
  • Incandescent Lights With Exterior Switch
  • Anti-Condensate Door Perimeter Heaters
  • High-Quality Stainless Steel Exterior Front
  • Magnetic Snap-In EZ-Clean Door Gaskets
  • Set of Four (4) 6" High Casters With Locks
  • Stainless Steel One-Piece Louver Assembly
  • Damage-Resistant Stainless Steel Breaker Caps
  • Full or Half Length Hinged Glass Doors With Locks
  • Load-Sure Guard Protects Against Improper Loading
  • Microprocessor Control With LED Temperature Readout
  • Corrosion-Resistant Anodized Aluminum One-Piece Sides
  • Self-Closing Doors With Stay Open Feature At 120 Degrees
  • Large High Humidity Evaporator Coil Outside The Food Zone
  • Top-Mounted, Balanced, Self-Contained Refrigeration System
  • Energy-Saving Automatic Non-Electric Condensate Evaporator
  • Thermostatic Expansion Valve Metering Device Provides Quick Refrigeration Recovery Times
  • Three (3) Adjustable Epoxy-Coated Shelves Per Section, Supported On Shelf Pins (installed at the factory)
Optional Accessory Kits:
  • Additional Epoxy-Coated Shelves
  • Plated Shelves* (for use in lieu of standard shelving)
  • 6" High Adjustable Legs (for use in lieu of standard casters)
  • EZ-Change Interiors (#1, universals, universal heavy-duty tray slides and shelves)
  • No. 4 Type Tray Slides* To Accommodate (1) 18" x 26" Sheet Pans (equips one full section)
  • No. 1 Type Tray Slides* To Accommodate either: (1) 18" x 26" or (2) 14" x 18" Sheet Pans, Adjustable To 2" O.C.
  • Universal Type Tray Slides* To Accommodate Either (1) 18" x 26" or (2) 14" x 18" Sheet Pans, or (2) 12" x 20" Steam Table Pans, Adjustable To 4" O.C.
    • Please refer to spec sheet TR35872 for optional accessory kit details.
    • All optional accessory kits are shipped separately for later installation by others at the job site.
Specifications:
Construction, Hardware, and Insulation
  • Cabinet exterior front and louver assembly are constructed of 20-gauge stainless steel. Cabinet sides (including returns) and interior are constructed of anodized aluminum. The exterior cabinet top, back, and bottom are constructed of heavy gauge aluminized steel. A set of four (4) 6" high casters are included. Doors are equipped with removable plug cylinder locks and guaranteed for life cam-lift, gravity action, self-closing metal, glide hinges with a stay-open feature at 120 degrees. An exterior mounted switch is provided to operate the interior incandescent lighting. Each door includes a vertically mounted stainless steel handle. Gasket profile and Santoprene® material simplify cleaning and increase overall gasket life. Anti condensate heaters are located behind each door opening. The cabinet is insulated with an average of 2" thick high-density, non-CFC, foamed-in-place polyurethane.
Refrigeration System
  •  A top-mounted, self-contained, balanced refrigeration system using R-134a refrigerant is conveniently located behind the one-piece louver assembly. It features an easy-to-clean front-facing condenser, thermostatic expansion valve, air-cooled hermetic compressor, large, high humidity evaporator coil located outside the food zone and a top-mounted non-electric condensate evaporator. A 9' cord and plug are provided. Standard operating temperature is 34 to 38°F.
Controller
  • The easy-to-use water-resistant microprocessor control system is supplied standard. It ­includes a 3-Digit LED Display, and a Fahrenheit or Celsius Temperature Scale Display Capability.
Interior
  • Standard interior arrangements include three (3) epoxy-coated wire shelves per section, mounted on shelf pins, installed at the factory. Shelves are full-width, and do not have any large gaps between them requiring the use of "bridge" or "junior shelves." Recommended load limit per shelf should not exceed 225 lbs.
Warranties
  • Both a three-year parts and labor warranty and a five-year compressor warranty (self-contained models only) are provided standard.

Options for Traulsen G32003

Right section additional tray slides & shelves (for use with shelf and tray accessories)
Left section additional tray slides & shelves (for use with shelf and tray accessories)
Center section additional tray slides & shelves (for use with shelf and tray accessories)
Export crating#
Mounting options
What is included
  • Warranty: 6-year parts & labor and 7 year compressor, standard. Visit www.traulsen.com for details
  • Oversize Note: Oversized units with crated shipping dimensions greater or equal to 72" in length and/or 90" in height. If delivery is to a facility without a standard height dock, additional shipping charges will apply, depending on the service requested (consult factory for details)
  • Voltages: 115v/60/1-ph, 14.4 amps, NEMA 5-15P, 1/4 HP, standard
