Traulsen TBC1H-20 Spec-Line Roll-In Blast Chiller with EPICON Control

Traulsen TBC1H-20 Spec-Line Roll-In Blast Chiller with EPICON Control

TBC1H-20
Stock Status
Updating. Please wait...
Free Freight
$78,526.80

Contact us for your price

Call 1 (800) 555-0666
Mon-Fri 9AM-8PM, Sun 12-6PM ET

Why don't we show the price for this item?

$74,957.40

Contact us for your price

Call 1 (800) 555-0666
Mon-Fri 9AM-8PM, Sun 12-6PM ET

Why don't we show the price for this item?

You will earn 78527 Reward Points.

Product Protection
Coverage starting at
FINANCE

Monthly Payment *

Finance Payment Calculator
$1,610.83
* The above amount may vary depending on the applicant's credit history.
  • 2023 model, meets the newest EPA and DOE codes.
  • NOTE! Requires remote refrigeration system (not included)
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Traulsen TBC1H-20 Specifications

Installation TypeFreestanding
BrandTraulsen
Refrigerant TypeR-404A
CertificationsNSF
Door StyleSwing
TypeRoll-In
Refrigeration SystemSelf-contained
Capacity1 Rack
Compressor LocationRemote
Door TypeSolid
Sections1
Temperature Range-27 - 41 Degrees F
Voltage115 Volts
Width (in)48.5
Height (in)90.38
Depth (in)37.63
Weight830

Traulsen TBC1H-20 Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Traulsen TBC1H-20 Description

Spec-Line Roll-In Blast Chiller with EPICON Control, holds (1) 27"W x 29"D x 72"H rack, self-contained holding refrigeration system, remote chilling refrigeration system not included, chills (300 lbs) 160°F to 40°F /155 minutes, hinged left, cETLus, NSF
Spec-Line Roll-In Commercial Blast Chiller with EPICON Control, hold (1) 72" high rack, self-contained holding refrigeration system, remote chilling refrigeration system not included, chills 150# - 250#, hinged left, cULus, NSF (more commercial refrigerators and freezers available)

Standard Features:
  • On-Board Cycle Data Printer
  • Epicon Touch Screen Control
  • Three (3) Year Parts & Labor Warranty
  • Self-Closing & Stay-Open Door Feature
  • Stainless Steel Door With Cylinder Lock
  • Magnetic, Snap-In EZ-Clean Door Gaskets
  • Stainless Steel Exterior & Interior Construction
  • Two (2) Year Additional Compressor Parts Warranty
  • TBC1H & TBC1HR Accommodate One 72" High Rack
  • TBC2H & TBC2HR Accommodate Two 72" High Racks
  • USB Port For Downloading Cycle Data & Software Updates
  • Guaranteed-For-Life Metal Door Handle & Cam-Lift Hinges
  • Automatic Maintenance Mode After Each Chill/Freeze Cycle
  • On-Site Service Validation (no-charge) To Insure Proper Installation of the Remote Condensing Unit
  • Three (3) Removable Food Probes & Three (3) Food Timers (6 probes & timers for TBC2H models) Allow For Easy Multibatching with or without Probes
The Exclusive Epicon™ Control:
  • Display Temp in °F or °C
  • 90-Day Cycle Data Memory
  • Adjustable Target Temps & Times
  • Advanced Data Management & Defrost
  • Two Easy Ways to Operate
    • AUTO: Hands-Free Cycle Start
    • MANUAL: Chill by Time-Temp-Recipe
  • Four Chilling Settings
    • SPEED: Reduce chill time by 10%
    • ENERGY: Save approx. 10% energy
    • STANDARD: For basic chill operation
    • DELICATE: For refreshing RTE foods
Options & Accessories:
  • Right or Left Hand Door Hinging
  • Correctional Facility Package for Blast Chill
  • Stainless Steel Finished Back (roll-in models only)
  • BCACC-OTRTR: Roll-In Rack Holds (26)12" x 20 " pans
  • BCACC-60018: 115V Floor-Mounted Condensate Evaporator
  • On-Board Label Printer (adhesive labels for product containers)
  • Water Cooled Self-Contained Condenser Suitable for Connection to Glycol (consult factory)
  • Combi Oven Compatibility Collar: Accommodates oven racks with max dimensions of 27-1/4" X x 37-7/16" D x 72" H*
  • *Note that some oven racks have a flange on the handle side. Please contact factory with full rack dimensions in order to determine if this can be accommodated.
Remote Condensing Units:
  • BCACC-60146-10: 460/60/3 4HP Air-Cooled
  • BCACC-60111-10: 208-230/60/1 4HP Air-Cooled
  • BCACC-60123-10: 208-230/60/3 4HP Air-Cooled
  • BCACC-60229: 208-230/60/3 5HP Water-Cooled
  • BCACC-60228-10: 208-230/60/1 5HP Water-Cooled
  • BCACC-60122-10: Weather Housing for Remote Condenser
  • *One remote condensing unit is required for models TBC1H and TBC1HT (2 for models TBC2H and TBCHR). These can be purchased either from Traulsen or elsewhere (see back page for remote condensing unit requirements).
Specifications:
Hardware, Insulation, and Construction
  • Exterior sides, front, door, and interior are constructed of stainless steel. Exterior top, bottom, and rear are constructed of heavy gauge galvanized steel. The interior floor is constructed of stainless steel and insulated with 3/4" of resilient cork. Door is equipped with a cylinder lock and guaranteed-for-life cam-lift, self-closing hinges with a stay-open feature. Santoprene® EZ-Clean door gasket simplifies cleaning and increases gasket life. Anti-condensate heater is located behind door opening. Both cabinet and door are insulated with high-density, non-CFC foamed-in-place polyurethane. It is important to note that models TBC2H and TBC2HR are shipped in two-pieces which must be joined together at the jobsite (by others).
Refrigeration System
  • Dual, high-capacity refrigeration systems using R-404A refrigerant are coupled with an advanced air circulation system to rapidly chill hot product safely through the HACCP danger zone. They feature a self-contained maintenance system, thermostatic expansion valve metering device, large, high humidity evaporator coil, high-speed evaporator fan, air-cooled hermetic compressor, and a hot gas defrost. Each model requires a separate 4 HP remote condensing unit for blast chill operation (two for models TBC2H and TBC2HR). The condenser coil is front-facing for easy cleaning. Defrost occurs automatically, intervals between defrost cycles can be adjusted to better suit differing operational needs. Each model requires provision of either a floor drain or optional condensate evaporator for condensate removal (two for models TBC2H and TBC2HR). The latter can be installed within the cabinet footprint in a compartment located in the bottom right corner of the cabinet. Each condensate evaporator requires a separate 115V outlet from the blast chiller. See TR35801 for details.
Interior Arrangements
  • Models TBC1H and TBC1HR each accommodate one (1) 72" high roll-in rack with maximum dimensions, wheels inboard of frame, of 27" wide x 29" deep. Models TBC2H and TBC2HR accommodate two of the same size roll-in racks. Racks are not supplied standard but are available from Traulsen as an optional accessory or may be purchased elsewhere.
Blast Chill Operation
  • In standard blast chill mode, air circulating in the food zone will cycle between 10- 14°F to promote rapid product chilling without freezing. Target temperatures can be adjusted between 40 and -5°F. When freezing product, air temperatures within the food zone will cycle as low as -25°F. During chill/freeze cycles, core product temperatures are measured and recorded by the food probes. Upon cycle completion the blast chiller notifies the operator with an audible alarm, and automatically switches into maintenance mode at either the default temperature (37°F) or the operator programmed target temperature.
Controller Basics
  • The easy-to-use, touch-screen epicon control is water-resistant and protected from damage by a heavy-gauge stainless steel bezel. Using the three food probes provided, it monitors cycle operation and records all data required for HACCP compliance. This can then be printed at the end of each cycle using the on-board printer and/or retrieved later from memory, where it is stored for 90-days. Product and user names can be manually input at the beginning or end of each individual chill cycle if desired, or loaded and stored in advance.
The Auto Mode
  • The control provides for "hands free" cycle start. Placement of any available food probe into hot product (90°F or greater) will begin a blast chill cycle within 60-seconds.
The Manual Mode
  • Custom cycle parameters (target temp/time & chill method) can be set with each use or input into the Product Menu by name in order to provide consistent chilling/freezing across a wide spectrum of different product requirements. Should the operator fail to complete programming a cycle, the control will automatically start this after five minutes elapses from the last button push (as long as a food probe had been placed in hot product).
Warranties
  • The unit is supplied standard with a three year parts & labor warranty on all components and the cabinet, and additional two-year parts only warranty on the compressor(s). These warranties cover the remote condensing unit if purchased from Traulsen.

Options for Traulsen TBC1H-20

Remote condensing unit
Stainless steel back
Correctional options
Options & accessories
What is included
  • Voltage: 115v/60/1-ph, 16.0 amps, standard
  • Warranty: 6-year parts & labor and 7 year compressor, standard. Visit www.traulsen.com for details
  • Oversize Note: Oversized units with crated shipping dimensions greater or equal to 72" in length and/or 90" in height. If delivery is to a facility without a standard height dock, additional shipping charges will apply, depending on the service requested (consult factory for details)
