Vulcan ARS36 Achiever 36" 2 Drawer Refrigerated Chef Base with Marine Edge Top - 115 Volts

ARS36
Made in USA
Stock Status
Updating. Please wait...
Free Freight
$15,406.00
Lowest Price Guarantee
Chat Now
$12,517.03

You will earn 15406 Reward Points.

Product Protection
Coverage starting at
FINANCE

Monthly Payment *

Finance Payment Calculator
$268.99
* The above amount may vary depending on the applicant's credit history.
  • 2023 model, meets the newest EPA and DOE codes.

Vulcan ARS36 Specifications

Width Range36 to 60 Inches
SeriesAchiever
ConstructionGalvanized & Stainless Steel
Top StyleMarine Edge
BrandVulcan
Refrigerant TypeR-404A
Size1 Section
Made inUSA
RefrigerationSide-mount
Interior FinishStainless Steel
Exterior FinishGalvanized & Stainless Steel
Casters3" heavy-duty
CategoryRefrigerated Counter, Griddle Stand
Capacity2 Full Size Food Pans
Compressor LocationSide Mounted
Number of Drawers2
Sections1
StyleDrawers
Voltage115 Volts
Width (in)36
Height (in)26
Depth (in)34
Weight290.00

Additional Information on Vulcan ARS36

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Vulcan ARS36 Description

Achiever Refrigerated Base, 36", self-contained, one-section, (2) drawers, marine top, stainless base, top, front, sides, interior, galvanized back, 3" heavy duty casters, magnetic drawer gasket, 1/3 hp, 115v/60/1, 6.7 amps

Standard Features:
  • Condenser filter
  • Marine edge top
  • Compressor on left
  • Off-cycle evaporator defrost
  • 4" casters in adjustable channels
  • Magnetic snap-in drawer gaskets
  • 14-guage stainless steel drawer slides
  • Automatic non-electric condensate filter
  • One year limited parts and labor warranty
  • Stainless steel top, front, sides and interior
  • Self-closing drawers with stay open feature
  • INTELA-TRAUL microprocessor control system
  • NEMA 5-15 plug with 9' cord and cord retainer
  • Controllable anti-condensate drawer perimeter heaters
  • Front-breathing design allows for zero clearance installation
  • Balanced, self-contained refrigeration system that utilizes R-404A
  • Side, front and rear access panels provide for ease of service and maintenance
Options
  • Compressor on right
  • 6" stainless steel legs
  • Export 220/50/1 voltage
  • 6" cabinet length extension
  • NAFEM data protocol gateway package
Specifications
Heliarc welded, fully insulated, stainless steel double pan Cabinet exterior front, sides, louver assembly and drawers are constructed of 20-gauge 430 stainless steel, exterior back and bottom are constructed of heavy gauge galvanized steel. Cabinet interior sides are constructed of 22-gauge 400 series stainless steel, top and bottom are constructed of 22-gauge 300 series stainless steel. A set of 4" high casters are included standard. Vinyl magnetic snap-in drawer gasket assures tight drawer seal. Both the cabinet and drawers are insulated with an average of 2" thick high density, non-CFC, foamed in place polyurethane. The easy to use water resistant INTELA-TRAUL® microprocessor control system is supplied standard. Unit is NAFEM Data Protocol communication (NDP) ready. Optional hardware required to be NDP compliant (3rd party software required for network connection). It includes a 3-Digit LED Display, °F or °C Temperature Scale Display Capability, and an RS485 data port. In addition it includes audio/visual alarms for: Hi/Lo Cabinet Temperature, Clean Condenser, Evaporator Coil and Discharge Line Sensor Failures, and Power Supply Interruption. The left side mounted, self-contained, balanced refrigeration system using R-404A refrigerant features an off-cycle defrost, capillary tube, air-cooled hermetic compressor, automatic condensate evaporator, and a dedicated rear mounted evaporator design which distributes cold air through each drawer section. A 9' cord and retainer is provided. Standard operating temperature is 34 to 38°F. Each heavy-duty drawer is designed to accommodate 12" x 20" x 6" deep pans. They are constructed using 14-gauge stainless steel drawer slides and 2" diameter stainless steel rollers. Drawers include both a self-closing and stay-open feature.
