Lang Manufacturing 160TDI Griddle
SKU#: 160TDI
1/5
Free Freight?
Quick Ship
$17,310.00
Calculate
Product Protection
Starting at
Lang Manufacturing 160TDI Specifications
| Installation Type | Drop-In |
|---|---|
| Type | Griddle |
| Construction | Stainless Steel |
| Brand | Lang Manufacturing |
| Certifications | NSF |
| Power Type | Electric |
| Number of Burners | 5 |
| Control Type | Thermostatic |
| Heat | Electric |
| Voltage | 208-480 Volts |
| Wattage | 30 Kilowatts |
| Width (in) | 60.8 |
| Height (in) | 11.1 |
| Depth (in) | 28.5 |
| Weight | 665.00 |
Additional Information on Lang Manufacturing 160TDI
middleby-financial-flyer.pdf
buying-guide.pdf
lang-manufacturing-160tdi.specsheet.pdf
warranty-sheet.pdf
installation-operation.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Lang Manufacturing 160TDI Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Lang Manufacturing 160TDI Description
Griddle, electric, Drop-In, 60"W x 28.2"D cooking surface, 1" thick highly polished steel griddle plate, 8 qt capacity grease trough with removable fully enclosed sleeve, Accu-Temp solid state controls (±2°F) every 12", stainless steel flange, 12.0/18.0kW, cETL, NSF
Commercial Drop-In Griddle, electric, 60"W x 28.2"D cooking surface, 1" thick highly polished steel griddle plate, 8 qt capacity grease trough with removable fully enclosed sleeve, Accu-Temp solid state controls (±2°F) every 12", stainless steel flange, 12.0/18.0kW, cETL, NSF (more flat top grills & griddles, commercial grills, commercial restaurant ranges, and cooking equipment available)
Construction Features:
Construction Features:
- Full parameter stainless steel top mounting flange
- 1” thick precision machined, polished steel cooking surface
- Separate, insulated stainless steel griddle and control modules
- 8 quart capacity grease drawer, with removable fully enclosed sleeve
Performance Features
- Recessed control panel protects controls
- Heating elements incoloy sheathed, for long life
- Accurate temperature control between 175˚ and 450˚F
- Thick griddle plate reduces hot & cold spots and retains heat
- Elements are pressure clamped to bottom of griddle plate for more even heating
- Highly polished, recessed surface and continuously welded mounting flange speeds cleanup
Control Package (Specify One)
- Accu-Temp-[TDI]
- Snap-Action thermostats
- Independent temperature control every 12”
- 175˚ to 550˚F temperature control, in 25˚ increments
- Solid State Controls react to a 2˚F temperature change
- Accu-Temp-[SDI]
- Independent temperature control every 12”
- RTD probe reacts to a 1˚ temperature change
- 175˚ to 450˚F temperature control, in 25˚ increments
- Area Sensitive Resistance Temperature Detector (RTD) System
