Cleveland Range 24CEA10 Steamcraft Gemini" 10 Pressureless Steamer
SKU#: 24CEA10
Free Freight?
Quick Ship
$28,123.73
Contact us for details
Calculate
Product Protection
Starting at
- Free Start-Up Program: Includes a performance check-out by Factory Authorized Servicer after installation and equipment demonstration by factory trained sales rep.
- Please see specification sheet for installation clearance requirements
Cleveland Range 24CEA10 Specifications
| Pan Capacity | 10 Pans |
|---|---|
| Steam Source | Boiler |
| Model type selection | Convection Steamers |
| Type | Convection Steamers |
| Boiler | Yes |
| Brand | Cleveland Range |
| Number of Compartments | 2 |
| Power Type | Electric |
| Control Type | Manual |
| Interior Finish | Stainless Steel |
| Legs | 6" stainless steel legs |
| Controls | Manual |
| Heat | Electric |
| Style | Floor with Boiler Base |
| Voltage | 208 Volts |
| Wattage | 32 Kilowatts |
| Width (in) | 24 |
| Height (in) | 65.5 |
| Depth (in) | 33 |
| Weight | 528.00 |
Additional Information on Cleveland Range 24CEA10
cleveland-range-24cea10.specsheet.pdf
warranty-sheet.pdf
owner-s-manual.pdf
service-manual.pdf
parts-manual.pdf
cookbook.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Cleveland Range 24CEA10 Description
Steamcraft® Gemini™ 10 Pressureless Steamer, electric, 2 compartments with individual generators, (5) 12 x 20 x 2-1/2 pans/compartment capacity, manual controls, easyTimer 90-minute timer with dial and LED digital readout in minutes and seconds, includes SureCook load compensating thermostat, manual cooking mode and descale indicator, left-hand hinged door, controls on right, steam shut-off switch, stainless steel construction, 6" stainless steel legs
Steamcraft® Gemini™ 10 Pressureless Steamer, electric, 2 compartments with individual generators, (5) 12 x 20 x 2-1/2 pans/compartment capacity, manual controls, 60-minute mechanical timer & manual (continuous steaming) by-pass switch, left-hand hinged door, controls on right, steam shut-off switch, stainless steel construction, 6" stainless steel legs
Standard Features:
- Left Hand Door Hinging: Compartment Doors hinged on the left, controls on the right.
- Condensate Drip Trough: Provide under lower compartment door to collect condensate.
- Cooking Capacity for up to ten 12˝ x 20˝ x 2 1⁄2˝ deep Cafeteria Pans, five each compartment.
- NSF Certified 6˝ Stainless Steel Legs with adjustable flanged feet for a one inch level adjustment.
- Durable 14 Gauge, Stainless Steel Construction: For compartment door, cavity and steam generator.
- Automatic Generator Drain: Contains a “Water Jet” Spray Rinse Drain Cleaning Cycle to keep drain clear.
- Easy Access Generator Cleaning Port: Two Generator Cleaning Ports located on the outside, top of the unit.
- Instant Steam Stand By Mode: Hold generator at a steaming temperature. Allows unit to start cooking instantly.
- Main Power On/Off Switch: Automatically fills generator with water, and then starts heating elements in generator.
- Each steam-cooking compartment is independently operated and controlled by a separate stainless steel steam generator.
- Two 60 Minute Electro-Mechanical Timers and Switches for manual operation: Audible signal for cooking time completion. (MCS)
- Exclusive Automatic Probe for Water Level Control: Separate from the generator for easy access, contains a high velocity rinse cycle to eliminate mineral build up.
- Exclusive “Cool to the Touch” Two-Piece Compartment Door Design: Free floating inner door with reversible gasket provides an air tight seal. Stainless Steel Slam/Latch Door Latch mechanism for reliability.
- Innovative PowerPak Electric Steam Generator: Twin Vertical Atmospheric Electric Steam Generators operate independently. Two 8 KW Fire Bar Heating Elements per generator. Strong 14 Gauge Stainless Steel Construction. Large 5 gallon generator reservoir for each compartment for high speed steam cooking production. Two fully insulated rear mounted independent steam generators.
- Exclusive Steam Cooking Distribution System: Exclusive Brass Steam Jets produce a high velocity convection steam without fans. Coved Corner design in cooking compartment distributes heat evenly, and is easy to clean. Creased top & bottom enhance drainage. Cold Water Condenser for each compartment maintains a dry steam. Fully Insulated cooking compartment for thermal efficiency. Removable Stainless Steel Slide Racks.
Options & Accessories:
- Water Filters
- 10˝ Stainless Steel Legs (LF10)
- Cafeteria Pans in depths of 1˝, 2 1⁄2˝ and 4˝
- Compartment Door Steam Shut Off Switch (SCS)
- Low Wattage Option, 8 KW each compartment (LWO)
- Right hand Door Hinging, Controls on the Right (DHR)
- Electronic Timer with Compensating Load Feature (ETC)
- ON/OFF Steam Switch only for compartment controls (MC)
- Dissolve ® Descale Solution, 6 one gallon container w/ quart markings (106174)
Cleveland’s “Best-in Class” product line offers the industry’s overall best “Standard Warranty Program” featuring:
- Free Performance Start Up with Water Quality Check
- Free Water Quality Check included with start up
- 1-Year Door Gaskets and Adjustments included
- 3, 5, 6 pan and 10 pan compartment steamers, non-part adjustments
- 2-Year K-12 School Warranty included
- 3-Year warranty included with purchase of Filter
- 2-Year Warranty with Filter Purchase from Cleveland
- Full 2-years parts and labor coverage
- 5-Year Prorated for Pressure Boilers and Steam Generators
- 100% covered for first 2 years with filter purchase
Specifications:
Two Compartments, Cleveland Convection Steamer series SteamCraft Gemini TM 10, Model 24-CEA-10, Twin Electric Atmospheric Steam Generator, 32 KW input. Remote Probe Type Water Level Controls. Steam Generator with Automatic Water Fill on start up. Automatic Generator Blowdown, Two each 16.5 KW Fire Bar Heating Elements. Choice of Compartment Controls, Manual By Pass Operation Mode, Exclusive Cold Water Condenser design, Type 430 Stainless Steel exterior and cooking compartments.
