Southbend P18C-P Platinum Heavy Duty Range

SKU#: P18C-P
Southbend P18C-P Platinum Heavy Duty Range
Free Freight?
Quick Ship
$7,175.00

Web price is showing. Call

$6,502.70

Web price is showing. Call

or enjoy small payments $139.74/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 7175
  • Please see specification sheet for installation clearance requirements
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Southbend P18C-P Specifications

BTU 16,000 BTU
Number of Burners1 - 2
Total BTU16000 - 130000
Installation TypeFreestanding
Burner StylePlancha
Range Base StyleStorage Base
BrandSouthbend
CertificationsNSF
Control TypeManual
HeatGas
Number of OvensNone
Width (in)18
Height (in)41
Depth (in)37.5
Weight270.00

Additional Information on Southbend P18C-P

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Southbend P18C-P Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Southbend P18C-P Description

Platinum Heavy Duty Range, gas, 18", 11-3/4" plancha, 1/2" thick plate, manual controls, battery spark ignition, cabinet base, stainless steel front sides, rear & exterior bottom & 6" adjustable legs, 16,000 BTU, CSA, NSF

Boasting a cooking power of 16,000 BTU, this 18" heavy-duty commercial gas range has a plancha at the top and a cabinet at the bottom to create a powerful cooking station that can help you meet daily demand. The front two-thirds of the cooking surface can get as hot as 800 degrees Fahrenheit for that perfect searing while the rest supports lower cooking temperatures ideal for finishing the meals. The plate is made of half-inch thick reinforced steel and is fitted with cast-iron burners that have excellent heat retention to keep preheat and recovery time short. The plate is slightly raised so you can easily clean the cooking surface.

The front of the plancha is a 5" deep rail while the rear and sides have splash guards to keep grease and food debris from escaping the unit. There are also 3" wide collection trays set up on the sides to separate waste from the previous cooking session.

This commercial range is mostly stainless steel-from the front, sides, cabinet, rear, exterior bottom, and 6" legs to protect from rust and corrosion. The lining and burner box are fully insulated to keep the operation efficient. Heat and smoke produced by the plancha during cooking are steered away from the user and into the vent hood by the 5" high stainless steel flue riser.

This heavy-duty range comes with CSA and NSF certifications. The unit can be integrated into a battery in any position.

Shop more premium-quality restaurant and heavy-duty ranges and commercial cooking equipment here at CKitchen to get the best deals!



Standard Features:
Plancha units have a raised griddle plate for easy cleaning of the cooking surface between loads. 3" wide collection on sides allows separation of waste for preparation of next fare. Plancha griddle is 1/2" thick reinforced steel plate powered by cast iron burners provides fast preheat and recovery time. High heat zone with max temperatures of 800°F located on front 2/3 of plate for quick sear with decreased temps on rear 1/3 of plate for product finishing.
  • 5" deep front rail
  • Battery spark ignition
  • Side and rear splashers
  • Free battery-design assistance
  • 5" high stainless steel flue riser
  • 1/2" thick reinforced griddle plate
  • Fully insulated lining and burner box
  • Stainless steel front, sides, rear, and exterior bottom
  • 1-1/4" front gas manifold and 1" rear gas connection
  • Increased capacity removable stainless steel grease drawer
  • One 16,000 BTU NAT (15,500 BTU LP) burners with one  control knob
  • 18" wide sectional range with 11-3/4" width plancha griddle available with a cabinet base or as a modular unit (for mounting on countertop, refrigerated or freezer base)
Standard Features of Cabinet-Base Model
  • Stainless steel cabinet base with a removable door that can hinge on the right or the left.
Options & Accessories
  • 24" or 36" high flue riser
  • External pressure regulator
  • Removable shelf inside cabinet
  •  Casters (front two casters lock)
  • Tray or tubular shelves (12" deep)
  • Extra-deep rear-extending flue riser
  • Open-frame base with casters for battery
  •  Cable restraint kit (to restrict movement when on casters)
  • Shelves on flue riser (one on 24" flue riser, one or two on 36" flue riser, 10" deep)
  • Front rail options:
    • Cutouts in front rail for saucepans
    • 7-1/4" deep front rail (to match old style sectional)
    • Square belly bar mounted on 7-1/4" deep front rail
Standard Construction Specifications
Exterior Finish: Front, sides, rear, and exterior bottom constructed of #3 polished 430 and 304 stainless steel. Range: 18"-wide front-manifold sectional range includes 11-3/4" width 16,000 BTU NAT (15,500 BTU LP) griddle with side and rear splashers and grease drawer. Front Rail: 5" deep front rail. Flue Riser: 5" high stainless steel flue riser. Battery: Unit can be in any position in a battery. If the unit is at the end of the battery, the end side will be solid (rather than have a coverplate over the end of the front manifold). Legs: 6" stainless steel adjustable legs standard. Cabinet Base: Stainless steel cabinet base with a removable door that can hinge on the right or the left.

Options for Southbend P18C-P

Continuous front rail & belly bar
Range depth
Gas types
Prison options
Stainless steel options
Extended warranty
Mounting options
What is included
  • Shipping location: Domestic Shipping, inside of North America (Contact factory for price)
  • Standard warranty: Standard (1) year limited parts and labor warranty (reference warranty document for details)

Southbend P18C-P Accessories

Southbend PCF48 Caster Frame PCF48
$3,923.50
Southbend PCF64 Caster Frame PCF64
$4,669.00
Southbend PCF72 Caster Frame PCF72
$5,317.50
Southbend PCF80 Caster Frame PCF80
$5,855.50
Southbend PCF96 Caster Frame PCF96
$6,297.00
