Southbend P18N-P Platinum Heavy Duty Range

SKU#: P18N-P
Southbend P18N-P Platinum Heavy Duty Range
Free Freight?
Quick Ship
$6,250.00

Web price is showing. Call

$5,664.38

Web price is showing. Call

or enjoy small payments $121.73/mo.
Lease Payment Calculate
Product Protection
Product Protection
Starting at
Reward Points
Reward Points
You will earn 6250
  • Please see specification sheet for installation clearance requirements
Additional Options and Accessories are Available.
Please call:
1 (800) 555-0666

Southbend P18N-P Specifications

Number of Burners1 - 2
BTU16,000 BTU
Total BTU16000 - 130000
Installation TypeModular
Range Base StyleModular Base
Burner StylePlancha
BrandSouthbend
CertificationsNSF
Control TypeManual
HeatGas
Number of OvensNone
Width (in)18
Height (in)13.5
Depth (in)37.5
Weight240.00

Additional Information on Southbend P18N-P

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

Southbend P18N-P Certifications

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

Southbend P18N-P Description

Platinum Heavy Duty Range, gas, 18", modular, 11-3/4" plancha, 1/2" thick plate, manual controls, battery spark ignition, stainless steel front sides, rear & exterior bottom, 16,000 BTU, CSA, NSF


This heavy-duty commercial gas range with a battery spark ignition lets you install a plancha on your counter or refrigerated/freezer base, adding 16,000 BTU of cooking power without taking up additional floor space. The plancha is made of a half-inch thick reinforced steel plate and is equipped with a burner made of cast iron so it retains heat longer and speeds up recovery time in between sessions. With a predominant stainless steel construction including the front, sides, rear, and exterior bottom, this commercial range can comfortably handle rigorous tasks.

The front two-thirds plate serves as the high-heat zone where products can be seared to perfection at temperatures of up to 800 degrees Fahrenheit. You can put the finishing touches at the rear one-third of the plate, where the temperature is decreased. A 5" deep rail is installed at the top while splash guards surrounding the rear and sides to protect from spills and splashes.

Designed to facilitate a "cook more, clean less" operation, this heavy-duty range sets the plate higher so the cooking surface is easily accessible and cleanable. The 3" wide collection tray on the sides separates the waste for easy discarding. The lining and burner box are fully insulated to keep the operation efficient. The heat and smoke that come from the plancha is pulled away from the user and into the vent hood by the 5" high stainless steel flue riser.

This commercial gas range comes with CSA and NSF certifications. The unit can be integrated into a battery in any position.

Shop more premium-quality restaurant and heavy-duty ranges and commercial cooking equipment here at CKitchen to get the best deals!



Standard Features:
Plancha units have a raised griddle plate for easy cleaning of cooking surface between loads. 3" wide collection on sides allows separation of waste for preparation of next fare. Plancha griddle is 1/2" thick reinforced steel plate powered by cast iron burners provides fast preheat and recovery time. High heat zone with max temperatures of 800°F located on front 2/3 of plate for quick sear with decreased temps on rear 1/3 of plate for product finishing.
  • 5" deep front rail
  • Battery spark ignition
  • Side and rear splashers
  • Free battery-design assistance
  • 5" high stainless steel flue riser
  • 1/2" thick reinforced griddle plate
  • Fully insulated lining and burner box
  • Stainless steel front, sides, rear, and exterior bottom
  • 1-1/4" front gas manifold and 1" rear gas connection
  • Increased capacity removable stainless steel grease drawer
  • One 16,000 BTU NAT (15,500 BTU LP) burners with one  control knob
  • 18" wide sectional range with 11-3/4" width plancha griddle available with a cabinet base or as a modular unit (for mounting on countertop, refrigerated or freezer base)
Standard Features of Cabinet-Base Model
  • Stainless steel cabinet base with a removable door that can hinge on the right or the left.
Options & Accessories
  • 24" or 36" high flue riser
  • External pressure regulator
  • Removable shelf inside cabinet
  •  Casters (front two casters lock)
  • Tray or tubular shelves (12" deep)
  • Extra-deep rear-extending flue riser
  • Open-frame base with casters for battery
  •  Cable restraint kit (to restrict movement when on casters)
  • Shelves on flue riser (one on 24" flue riser, one or two on 36" flue riser, 10" deep)
  • Front rail options:
    • Cutouts in front rail for saucepans
    • 7-1/4" deep front rail (to match old style sectional)
    • Square belly bar mounted on 7-1/4" deep front rail
Standard Construction Specifications
Exterior Finish: Front, sides, rear, and exterior bottom constructed of #3 polished 430 and 304 stainless steel. Range: 18"-wide front-manifold sectional range includes 11-3/4" width 16,000 BTU NAT (15,500 BTU LP) griddle with side and rear splashers and grease drawer. Front Rail: 5" deep front rail. Flue Riser: 5" high stainless steel flue riser. Battery: Unit can be in any position in a battery. If the unit is at the end of the battery, the end side will be solid (rather than have a coverplate over the end of the front manifold). Legs: 6" stainless steel adjustable legs standard. Cabinet Base: Stainless steel cabinet base with a removable door that can hinge on the right or the left.

Options for Southbend P18N-P

Continuous front rail & belly bar
Range depth
Mounting note
Gas types
Prison options
Stainless steel options
Extended warranty
Mounting options
What is included
  • Shipping location: Domestic Shipping, inside of North America (Contact factory for price)
  • Standard warranty: Standard (1) year limited parts and labor warranty (reference warranty document for details)
