Description
Duke E-5-DLSS Description Thurmaduke™ Steamtable Unit, electric, 74"W x 34"D x 36"H, 16ga stainless steel top, (5) stainless steel sealed wells, drains, copper manifolds, (1) brass valve, thermostat controls, integral stainless steel cutting board, dish shelf, 20ga stainless steel body & undershelf, 6"H stainless steel legs with adjustable feet, cULus, UL EPH Classified NOTE: Electric values & plug configurations change for 3 phase or when adding electric options - Contact Factory for more info)
Options for Duke E-5-DLSS Serving shelves & sneeze guards Cutting board/shelf - customer's side Cutting Board, customer's side, 7"D, 1/2" white poly, 18ga stainless steel shelf, (3) fixed brackets, shelf mounted flush to counter top (No hinged brackets) +$1,568.57
Cutting Board/Shelf, customer's side, 7"D, 18ga stainless steel shelf, (3) fixed brackets, shelf mounted flush to counter top (specify any special height) +$842.17
Cutting Board/Shelf, customer's side, 7"D, 18ga stainless steel shelf, (3) hinged brackets, shelf mounted flush to counter top (specify any special height) +$1,325.38
Cutting Board, customer's side, 10"D, 1/2" white poly, 18ga stainless steel shelf, (3) fixed brackets, shelf mounted flush to counter top (No hinged brackets) +$1,773.54
Cutting Board/Shelf, customer's side, 10"D, 18ga stainless steel shelf, (3) fixed brackets, shelf mounted flush to counter top (No hinged brackets) +$1,047.13
Cutting Board/Shelf, customer's side, 10"D, 18ga stainless steel shelf, (3) hinged brackets, shelf mounted flush to counter top +$1,530.34
Fabrication, electrical & special body modifications Move cord set to operator's left +$108.32
Push bar, stainless steel handle & brackets, mounted on operator's right end (specify if left end) +$211.34
Bumpers (3" x 3" rubber corners) (per set) +$179.48
Round cutout with raw edge, in counter top, body panel or a shelf (specify cutout diameter & location) +$86.02
Round cutout with grommet, in counter top, body panel or a shelf (specify cutout diameter & location) +$86.02
Rectangular cutout with raw edge, must be 12" or less, in counter top, body panel or a shelf (specify cutout size & location) +$86.02
Rectangular cutout with reinforced edges, in counter top, body panel or a shelf, counter top max. right to left is 4" less than unit length (specify cutout size & location) +$212.40
Rectangular cutout with reinforced turn down edges & corners welded closed, in counter top, body panel or a shelf, counter top max. right to left is 4" less than unit length (specify cutout size & location) +$658.44
Electric outlet, mounted in base, with galvanized junction box, duplex or single receptacle & stainless steel cover, not wired +$202.84
Electric outlet, mounted in base, with galvanized junction box, duplex or single receptacle & stainless steel cover, wired to existing power source +$320.72
Omission of shelves, open base +$945.18
Special height legs (per leg) (shorter height voids NSF approval) +$82.84
Special Height Body, per unit
For special width body…per unit +$414.18
Body latches for holding portable units together, pair +$161.42
Filler panel for special length, mounted on end, enclosed both sides & end, includes longer counter top, longer tray slide if needed, no other equipment in filler +$414.18
Individual brass valves +$754.02
Pedestal-type duplex outlet, mounted, not wired +$464.09
Pedestal-type duplex outlet, mounted, wired to existing power source +$630.83
Tier of stainless steel angle slides in base - to hold (4) trays, pans etc. +$862.34
Modified base - to accept roll warmer (warmer by other manufacturers) not wired...per roll warmer +$760.39
For pass-thru construction +$414.18
No Drains, in lieu of standard drains
Locate drains on left +$108.32
Exposed element hot food wells with stainless spillage pan, in lieu of standard wells in a (5) well unit +$860.22
Tray slide - customer's side Tray Slide on fixed brackets, (3) bar tubular, 1" dia. stainless, end caps, mounted 34"H (specify any other height), NSF +$880.40
Tray Slide, customer's side, (3) tubular Ø 1" bars, stainless steel, on hinged brackets, end caps, mounted 34"H (specify any other height) +$974.92
Doors - customer's side Sliding doors, customer's side, with lock and keys, stainless steel, and recessed stainless steel pull (not available on gas models) +$2,618.89
Sliding doors, stainless steel, for customer's side of hot food units with (5) openings (not available on gas models), UL, UL EPH Classified +$2,524.37
Doors - operator's side Sliding doors, operator's side, with lock and keys, stainless steel, and recessed stainless steel pull (not available on gas models) +$1,348.74
Sliding doors, stainless steel, for operator's side of hot food units with (5) openings (not available on gas models), UL, UL EPH Classified +$1,254.22
Voltage options 120v/60/1-ph, 3750 watts, 31.3 amps
208v/60/1-ph, 3750 watts, 18.0 amps
208v/60/3-ph, 3750 watts, 10.4 amps +$272.93
240v/60/1-ph, 3750 watts, 15.6 amps
240v/60/3-ph, 3750 watts, 9.0 amps +$272.93
What is included NOTE:: Unit is designed to be used as a stand alone unit, not part of a serving systems line due to the body depth differences Close Description Duke Duke
E-5-DLSS
Electric Hot Food Serving Counter
with Controls,
