DC-12D Ice Cream Dipping Cabinet

Master-Bilt DC-12D Ice Cream Dipping Cabinet

DC-12D
Made in USA
Master-Bilt DC-12D Ice Cream Dipping Cabinet
$4,566.56
Request a Quote

You will earn 4,312 Reward Points. Earn 1 reward point for every 1 dollar spent.
Read more.

FINANCEFOR $108.14/mo.
Free Freight

Compressor warranty
5 year compressor part warranty

Warranty
2 year parts and labor warranty

Description
Ice Cream Dipping Cabinet, dip (18) 3 gallon, store (15) 3 gallon, cold-wall evaporator, painted textured galvanized steel exterior, galvanized steel interior, stainless steel top with anti-condensate heater, flip lids, temperature range 10 to -10F, 1/3 hp, 115v/60/1-ph, 7.5 amps (semi-hermetic), 9' cord, NEMA 5-15P, NSF, UL

Standard Features:
  • Construction:
    • Gasket
    • Stainless steel
    • Hinged with handles
    • Galvanized steel interior
    • Seamless stainless steel top
    • Floor drain with garden hose fitting
    • Anti-condensate heaters under stainless top cap
    • 24 gauge painted textured galvanized steel cabinet
    • Galvanized steel inner liner with cold wall evaporator
    • 21/4" foamed-in-place “zero ODP” urethane insulation LIDS
    • Equipped with leveling legs to correct for unlevel flooring situations
  • Refrigeration:
    • R-factor (insulation efficiency rating): 19.40
    • Temperature range: 10° to -10°F (-12° to -23°C)
    • Self-contained, factory tested refrigeration system
    • Refrigerant: DC-12D - R-404A, All other models - R-134a
    • Minimum 4" clearance required between cabinet back and wall
    • Force draft hermetic condensing unit (semi-hermetic unit on DC-12D with wire and tube condenser for low maintenance)
Warranty:
  • Standard limited two year parts and labor
  • Additional three year coverage on compressor part
Options:
  • Legs
  • Casters
  • Lid locks
  • Dipper well
  • Additional lids
  • Custom colors
  • Load level shelves
  • Add suffix “SE” for all stainless exterior
Specifications:
Cabinet will feature textured finish on exterior with galvanized steel interior. Cabinet to have flip lids, seamless stainless steel top, 24 gauge steel walls, galvanized steel inner liner with cold wall evaporator, anti-condensate heaters under stainless steel top, 21/4" foamed-in-place “zero ODP” urethane insulation and baked-on polyester enamel finish. Standard leveling legs provided to correct for unlevel flooring situations. The refrigeration system will be self-contained. DC-12D will contain R-404A refrigerant and all other models will contain R-134a. The temperature range will be 10° to -10°F (-12° to -23°C). Cabinet to have standard limited two year parts and labor with additional three year coverage on compressor part. Cabinet to be UL, C-UL (on all except DC-12D) and NSF listed.

Options
Finish options (exterior) - PLEASE CHOOSE ONE
Compressor warranty
Warranty
Specifications
Cabinet TypeIce Cream Dipping Cabinets
BrandMaster-Bilt
Number of Gallon3 gallon
Made inUSA
Certifications5-15P
Interior FinishStainless Steel
Exterior FinishStainless Steel
Temperature Range10 to -10 F
Width (in)84.63
Height (in)34.13
Depth (in)30.13
Weight490
You May Also Need
A060-20400 Dipper Well
$245
A044-11129 Lid Locking Kit
$166
44-00471 Lids
$221
A044-11140 Casters
$109
A044-11170 Legs Kit
$107


Additional Information

A PDF viewer is required to view this product's information.
Download Adobe Acrobat software

5-15P

5-15P

Two-pole with ground pin plug

NSF

NSF

This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.

UL

UL

UL has tested representative samples of this product and determined that the product meets specific, defined requirements.
