Vulcan VCCG48-AS 48'' Countertop Gas Griddle with Thermostatic Controls - 120,000 BTU
Energy Star ?Chat Now
Calculate
Vulcan VCCG48-AS Specifications
| Plate Thickness | 1 Inch |
|---|---|
| Total BTU | 105000 - 156000 |
| Installation Type | Countertop |
| Power Type | Natural or Propane Gas |
| Construction | Stainless and Aluminized Steel |
| Cooking Surface Material | Stainless Steel |
| With Griddle | Yes |
| Brand | Vulcan |
| Energy Efficiency | Energy Star |
| Made in | USA |
| Certifications | NSF |
| Number of Burners | 4 |
| BTU | 120,000 BTU |
| Control Type | Thermostatic |
| Heat | Gas |
| Usage | Heavy Duty |
| Voltage | 120 Volts |
| Width (in) | 48 |
| Height (in) | 18.8 |
| Depth (in) | 33.1 |
| Weight | 575.00 |
Additional Information on Vulcan VCCG48-AS
parts-manual.pdf
owner-s-manual.pdf
owner-s-manual-french.pdf
service-manual.pdf
sell-sheet.pdf
vulcan-vccg48-as.specsheet.pdf
warranty-sheet.pdf A PDF viewer is required to view this product's information.
Download Adobe Acrobat software
Vulcan VCCG48-AS Certifications
NSF
This mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today.
Vulcan VCCG48-AS Description
The 48” wide griddle on the VCCG48-AS Heavy Duty Griddle from Vulcan is an easy pick for any operation that does a lot of griddling. This countertop model is a heavy-duty gas-heated model that features thermostatic controls to accurately cook food for easily repeatable results. The polished steel griddle plate is 1” thick allowing it to easily retain heat from the atmospheric burners. The thick griddle plate also evens out the heat produced by the burners eliminating hot and cold spots on the cooking surface.
Precise control of the temperature is provided by four control knobs that can be set from 200°F to 550°F to get the results you need. To evenly apply heat to the griddle plate the four 30,000 BTU/hr atmospheric burners are spaced 12” apart. For ease of use, this griddle comes with a pilot protection system and electronic ignition.
The sides, front, and front top ledge are made from stainless steel making it easy to clean the exterior and ensuring the unit will maintain its looks for years to come. The internal structure features fully welded aluminized steel to make sure it can stand up to the rigors of daily commercial use. To make grease removal easy, this griddle features a 6 qt. stainless steel grease drawer that is easy to remove from the front or emptying whenever it’s convenient.
The cooking height of this griddle comes in at 14.7” and it is mounted on adjustable 4” legs to easily keep it level on the counter.
To connect this griddle to a standard 120v outlet it comes with a 6’ power cord prewired with a 5-15 plug. In total the required gas input of this unit is 120,000 BTU/hr.
Standard Features:
- Chrome plated knob guards.
- 1" thick polished steel griddle plate.
- 14.7" cooking height on 4" adjustable legs.
- One year limited parts and labor warranty.
- Electronic ignition with pilot protection system.
- Stainless steel front, sides and front top ledge.
- Stainless steel 4" back and tapered side splashes.
- Fully welded stainless and aluminized steel chassis.
- 3⁄4" rear gas connection and internal gas pressure regulators.
- 120V 50/60 Hz. 2 Amp single phase with NEMA 5-15 USA plug.
- High capacity, stainless steel grease drawer (6 quart). 60" and 72" models have two grease drawers.
- Energy-efficient 24,000 BTU/hr. infrared burner or 30,000 BTU/hr. atmospheric burner for every 12" of griddle width.
- Every 12" griddle cooking zone is independently controlled by solid state temperature and electronic ignition system with diagnostics.
- Temperature adjusts from 150° to 550° F on Steel or Chrome plate. Temperature adjusts from 150° to 450° F on Rapid Recovery™ plate.
- Top seam welding available on steel plate.
- Side grease models with 3.75 gallon grease drawer.
- Grooved steel plate (available with top seam welding).
- Chrome griddle plate (not available with top seam welding).
- Cutting board, condiment rail, plate rail and banking strip accessories.
- Rapid Recovery™ griddle plate (150-450° F controls, 60" maximum length, standard with top seam welding).
Heavy duty gas griddle. Stainless steel front, sides and front top ledge. Fully welded stainless and aluminized steel chassis. 14.7" cooking height on 4" legs. 1" polished steel griddle plate. Stainless steel back and tapered side splashes. Energy-efficient 24,000 BTU/hr. infrared burner or 30,000 BTU/hr. atmospheric burner for every 12" of griddle width. Every 12" griddle cooking zone is independently controlled by solid state temperature and electronic ignition system with diagnostic feature. Temperature adjusts from 150° to 550° F on Steel or Chrome plate. Temperature adjusts from 150° to 450° F on Rapid Recovery™ plate. Electronic ignition with pilot safety system. High capacity 6 quart stainless steel grease drawer. 120V 50/60Hz 2 amp single phase with NEMA 5-15 USA plug. 3⁄4" rear gas connection and internal gas pressure regulators. CSA Design Certified. NSF Certified.
